175
Key Features
Excellent power-to-weight performance.
Choose from Mechanical or Digital Electronic Control options.
Integrated Hydraulic Steering for a clean and tidier engine well.
Raised chrome graphics for premium look and finish.
TotalTilt function for fast and easy engine up or down tilting. Select models only.
Large 50-amp alternator to power onboard electronics.
Features & benefits
Quick Acceleration
Offset Crankshaft
The 10mm Offset Crankshaft allows for larger intake volume and intake tubes.
Boosts engine torque in the low and mid-speed ranges for quicker acceleration.
Better Charging
High Output Alternator
With up to 50-amps, the high-output alternator delivers plenty of power to keep charging the battery even a low RPM.
Provides plenty of power to run an array of electronic devices.
Optimum Power
Multi-Point Electronic Fuel Injection
Working in unison with multiple sensors and the electonic control unit, the Multi-Point Electronic Fuel Injection (EFI) system injects the right air - fuel mixture at the optimum timing.
Delivers maximum engine performance and quick engine starts."
Power to Weight
16-Valve DOHC Engine
A proven 2.8 Litre, 16-valve double overhead camshaft (DOHC) In-Line design, with four valves per cylinder maximises efficiency and power.
The streamline design achieves an impressive power-to-weight performance.
Precise Control
Variable Trolling Control
Yamaha’s variable trolling control lets the skipper adjust engine idle speed in 50 RPM increments via the digital gauge.
This allows you to set a precise trolling speed for better lure presentation when targeting different fish species.
Safety First
Prop Warning Light
This optional feature is exclusive to Helm Master EX joystick system, with the light mounted directly in the rear apron of the outboard.
The light provides a visual safety warning when a Helm Master EX SetPoint mode is active.
Feature-Rich Control
Digital Electronic Control
Advanced features include:
Push button up and down Speed Control and Pattern Shift for slower than idle speed trolling.
Neutral Hold for engine warm up or charging batteries and Station Selector for selecting more then one helm.
Engine Protection
Tilt Limiter
Available on Mechanical Control (MEC) outboards, the built-in tilt limiter automatically stops engine tilt at a set point.
This prevents the cowling from hitting bait boards or other boat parts.
One Touch Tilting
Total Tilt with Limiter
Yamaha’s exclusive TotalTilt™ function allows full tilt up or down of the outboard with a simple double-press of the tilt button.
A built-in limiter protects the engine from tilting too far.
Available on Digital Electronic Control (DEC) Models only.
Yamaha Advantage
Built tough.
Legendary Reliability
Smooth & Whisper Quiet
Shift dampening props, labyrinth exhaust systems, water-sealed outer shaft walls and noise-suppressing cowlings are just some of the technologies that help Yamaha outboards achieve such smooth and whisper quiet operation.
Fuel Efficiency
Yamaha’s Multi-Point Electronic Fuel Injection (EFI), vapor management and low-emission technologies are just some of the reasons why Yamaha outboards deliver excellent fuel economy and reduced emissions.
Four-stroke Advantage
Utilising advanced Electronic Fuel Injection (EFI) and engine management technologies, Yamaha four-stroke outboards are extremely powerful, smart, efficient and environmentally friendly.
2+2 Year Warranty
Yamaha outboards are covered under a two-year Manufacturer’s warranty, plus an extra two-years Extended Warranty for Customers who complete their scheduled services with an Authorised Yamaha Outboard Dealer. VMAX V6 models receive a two-year, plus one-year extended warranty.
Yamaha Built Componentry
We build our own gauges, throttles, props and other rigging componentry, to deliver a completely integrated and seamless engine ecosystem for superior outboard performance.
Japanese Quality
Uncompromising attention to detail, precision engineering and a continuous improvement philosophy make Japanese-made Yamaha outboards renowned for their exceptional quality, durability and performance.
Legendary Reliability
There’s a reason more Australian boaters choose Yamaha outboards. Yamaha has earned a reputation for building the world’s most reliable outboards, allowing you to relax and enjoy your time on the water.
175
F175C
F175CC
175
Meet the line up
Overview
Compatibility
Colours
Operation Method
Steering System
Tiller
Trim & Tilt Method
Digital Gauges
Electronic Key System
Specifications
Engine Type
Configuration
Bore x Stroke (mm)
Displacement (cm3)
Recommended Max RPM
Weight (kg)
Dry weight without prop.
Transom Height
Starter Method
Fuel Tank Capacity (L)
Fuel Induction System
Alternator Output
Gear Ratio
F175C
Signature Grey
Pearlescent White
Mechanical Control
Integrated Hydraulic
N/A
Power Trim & Tilt
CL5
6Y8
No
In-Line 4 - 4 Stroke
16-Valve DOHC Direct-Action
96 x 96.2
2785
5000-6000
F175LC: 233 F175XC: 234
L: 516mm (20.3”) X: 643mm (25.3”)
Electric
-
Electronic Fuel Injection
50A
1.86 : 1
F175CC
Signature Grey
Pearlescent White
Digital Electronic Control
Integrated Hydraulic
N/A
TotalTilt™
CL5
6Y8
Yes
In-Line 4 - 4 Stroke
16-Valve DOHC Direct-Action
96 x 96.2
2785
5000-6000
F175XCC: 235
X: 643mm (25.3”)
Electric
-
Electronic Fuel Injection
50A
1.86 : 1
